CanGas® Containerized High Pressure Nitrogen Generator Unit

CanGas® HPNGU series Containerized High Pressure Nitrogen generation unit

CanGas® HPNGU series Nitrogen generation unit is a containerized Nitrogen generation system, developed for oil and gas applications, especially for under-balanced drilling (UBD) and enhanced oil recovery, highly compact, 2 types of driving models and versatile adaptability design, both PSA and membrane technologies are available. The CanGas® HPNGU series of Nitrogen unit is excellent in performance, convenience and stability.


CAPN-HPC Nitrogen Generation Unit

System Features

  • Time-proven PSA Nitrogen Separation technology.

  • Smart Control: Standard CANBUS color touch screen automatic control system.

  • Compact: heavy-duty skid and containerized solution for easy deployment and reduced cost.

  • Widely used and reliable Oil-free Nitrogen Booster.

  • Many Optional Configurations: High adaptability.

  • Reliable performance with much lower cost, much lower energy consumption.


CAME-HPC Nitrogen Generation Unit

System Features

  • Membrane Nitrogen Separation technology.

  • Smart Control: Standard CANBUS color touch screen automatic control system.

  • Compact: heavy-duty skid and containerized solution for easy deployment and reduced cost

  • Widely used and reliable Oil-free Nitrogen Booster

  • Many Optional Configurations: high adaptability.


CAPN-HPC Nitrogen Generation Unit

Consisted of air compressor, PSA Nitrogen generator, oil-free Nitrogen booster, customized containers, etc.

ModelCAPN-600HPCCAPN-900HPCCAPN-1200HPC
Capacity600NM3/h(21178SCFH)900NM3/h(31761SCFH)1200NM3/h(42348SCFH)
Purity95%(95% - 99.999% Adjustable)
Outlet Pressure25Mpa35Mpa50Mpa
Driving ModelDiesel-powered or Electric-powered
StructureHeavy-duty skid and containerized

※ Other capacities/flows are available & customizable.


CAME-HPC Nitrogen Generation Unit

Consisted of air compressor, membrane N2 generator, oil-free Nitrogen booster, customized containers, etc.

ModelCAME-600HPCCAME-900HPCCAME-1200HPC
Capacity600NM3/h(21178SCFH)900NM3/h(31761SCFH)1200NM3/h(42348SCFH)
Purity95%(95% - 99.999% Adjustable)
Outlet Pressure25Mpa35Mpa50Mpa
Driving ModelDiesel-powered or Electric-powered
StructureHeavy-duty skid and containerized

※ Other capacities/flows are available & customizable.


Main Application Fields
